- Brand: TEMEISHENG
- Model: V5
- Color Options: Black
- Signal-to-Noise Ratio: 70-80dB
- Amplifier Type: Dual-channel digital amplifier
- Usage: Outdoor performance & karaoke speaker
- Dimensions: Length 226mm * Width 160mm * Height 340mm
Specifications:
Bluetooth Chip and Version: BP1048B2
Effect Processing Chip: HicoreTech HC6288, quad-core DSP+MCU+CODEC+SDRAM 16M
Amplifier: ACME ACM8629*2, 4.5V-26.4V Padup 2x52W, dual-channel digital amplifier with audio effect processing algorithm
Bluetooth Protocols: Supports a2dp, avctp, avdtp, avrcp, hfp, spp, smp, etc.
Material: Wooden enclosure with leather covering + aluminum alloy panel/grill
Output Power: Max 120W
Frequency Response: 60Hz-20KHz (-10dB)
Speaker Units:
5-inch bass speaker x1 (outer diameter Φ133mm), magnet size Φ80x18mm, impedance 4Ω
2-inch treble speakers x2 (outer diameter 51mm), neodymium magnet size Φ15.4x4mm, impedance 4Ω
Signal-to-Noise Ratio: ≥78dB
Total Harmonic Distortion: ≤3%
Sensitivity: -95dBm ±3dBm
Transmission Power: Supports CLASS1/CLASS2/CLASS3, adjustable transmission power 6dBm
Input Voltage: DC 5V
Audio Type: Stereo
Charging Current: Supports USB PD fast-charging protocol
DC 5V: 0.5A
DC 12V: 1.3A
DC 20V: 1.6A
Operating Current: 7.3V battery, average 10A at 1kHz 0dBm
Shutdown Current: No current
Temperature Range: -25℃ to +65℃
Speaker Battery: 7.3V/5200mAh (18650 type battery with protection board, TYPE-C charging interface)
Transmission Range: ≥10 meters (line of sight)
Battery Life:
Around 5 hours at 50% volume
Around 2.5 hours at full volume
Standby time around 1200 hours
Charging Time: About 3.5 hours for a full charge
Features:
Supports Bluetooth speaker music play/pause
Supports music skipping (next/previous track)
Remote control supports U-disk/TF card digital song selection/playback
Electronic crossover with 3-way independent amplifiers
Supports external audio input playback
Dual DSP processing
Independent adjustment for instrument/microphone professional effects
Supports microphone input and effect adjustments
Compatible with Bluetooth-enabled smartphones, laptops, tablets, etc.
Supports karaoke functions such as vocal cancellation, microphone signal recording, microphone priority, etc.
Supports OTG live recording
Indoor/outdoor sound effect switching
Built-in wireless microphone receiver, paired with full-metal U-segment adjustable frequency microphone
This speaker is designed for outdoor performances and karaoke, offering powerful audio processing capabilities, Bluetooth compatibility, and a variety of features, making it suitable for parties and events.
